NISSAN 13510-2W201 Crankshaft Oil Seal
Genuine part. Fitment information is for reference only. To ensure 100% compatibility, please send us a message with your VIN number before ordering.
Categories
OEM / Alternate Numbers
Product Description
Part number 13510-2W201 is a genuine OEM Nissan crankshaft oil seal (SEAL-OIL, CRANKS), designed to provide dynamic sealing for the crankshaft, primarily on Nissan vehicles equipped with the ZD30 diesel engine. The primary function of the oil seal is to retain engine oil within the crankcase at the shaft exit point, preventing leaks and oil contamination of the timing drive or auxiliary components, while effectively preventing the ingress of external dust and contaminants.
Technical specifications:
- OEM part number: 13510-2W201
- Superseded / OEM reference: 135102W200
- Part type: Radial shaft seal / Crankshaft oil seal
- Fitting position: Front (timing cover / front end) position
- Material composition: Fluoroelastomer (FKM) or nitrile elastomer resistant to high temperatures and synthetic engine oils, featuring internal metal reinforcement and spring-energized sealing lips
- Operating characteristic: Continuous sealing performance under high rotational speeds and thermal stress
Symptoms of seal wear:
Over time and due to sustained high operating temperatures, the oil seal material can harden or wear out. Common signs of failure include oil leaks on the front of the engine block or around auxiliary equipment, engine oil dripping underneath the engine compartment, and increased oil consumption. Timely replacement is critical to prevent damage to drive belts and severe engine failure resulting from low oil levels.
Vehicle compatibility:
- Nissan Cabstar (F24) 3.0 TD [2008 - 2008] (SEAL-OIL,CRANKS (ZD30DDTI))
- Nissan Cabstar (F24M) 3.0 TD [2006 - 2016] (SEAL-OIL,CRANKS (ZD30DDTI))
- Nissan Civilian (W41) 3.0 D [2015 - 2017] (SEAL-OIL,CRANKS (ZD30))
- Nissan Nissan Truck (D22) 3.0 TD [2001 - 2005] (SEAL-OIL,CRANKS (ZD30DDT))
- Nissan Np300 F/Sbs (D22SS) [2009 - 2011] (SEAL-OIL,CRANKS)
- Nissan Nt-500 (G40M) [2013 - 2014] (SEAL-OIL,CRANKS)
- Nissan Nt400 Cabstar (F24FF) 3.0 TD [2017 - 2017] (SEAL-OIL,CRANKS (ZD30DDTI))
- Nissan Nt400 Cabstar (F24F) [2009 - 2011] (SEAL-OIL,CRANKS)
- Nissan Patrol (Y61) 3.0 TD [2000 - 2016] (SEAL-OIL,CRANKS (ZD30DDTI))
- Nissan Safari Pick Up (TY61) 3.0 TD [2012 - 2016] (SEAL-OIL,CRANKS (ZD30DDTI))
- Nissan Terrano2 (R20) [2002 - 2004] (SEAL-OIL,CRANKS)
- Nissan Tk55 (TK3) [2011 - 2011] (SEAL-OIL,CRANKS)
- Nissan Urvan (E25) 3.0 TD [2003 - 2007] (SEAL-OIL,CRANKS (ZD30DDTI))
- Nissan Urvan (E25) 3.0 D [2001 - 2007] (SEAL-OIL,CRANKS (ZD30DD))
Technical Specifications
| Brand | NISSAN |
|---|---|
| Weight | 0.020 kg |
Compatible Vehicles
| Make | Model | Engine | Year | Notes |
|---|---|---|---|---|
| Nissan | Atleon (TK3) | All Engines | 2011 - 2011 | SEAL-OIL,CRANKS |
| Nissan | Cabstar (F24) | 3.0 TD (ZD30DDTI) | 2008 - 2008 | SEAL-OIL,CRANKS (ZD30DDTI) |
| Nissan | Cabstar (F24M) | 3.0 TD (ZD30DDTI) | 2006 - 2016 | SEAL-OIL,CRANKS (ZD30DDTI) |
| Nissan | Civilian (W41) | 3.0 D (ZD30) | 2015 - 2017 | SEAL-OIL,CRANKS (ZD30) |
| Nissan | Nissan Truck (D22) | 3.0 TD (ZD30DDT) | 2001 - 2005 | SEAL-OIL,CRANKS (ZD30DDT) |
| Nissan | Np300 F/Sbs (D22SS) | All Engines | 2009 - 2011 | SEAL-OIL,CRANKS |
| Nissan | Nt-500 (G40M) | All Engines | 2013 - 2014 | SEAL-OIL,CRANKS |
| Nissan | Nt400 Cabstar (F24FF) | 3.0 TD (ZD30DDTI) | 2017 - 2017 | SEAL-OIL,CRANKS (ZD30DDTI) |
| Nissan | Nt400 Cabstar (F24F) | All Engines | 2009 - 2011 | SEAL-OIL,CRANKS |
| Nissan | Nt400 Cabstar (F24F) | 3.0 Turbo (ZD30DDTI) | 2008 - 2011 | SEAL-OIL,CRANKS (ZD30DDTI) |
| Nissan | Patrol (Y61) | 3.0 TD (ZD30DDTI) | 2000 - 2016 | SEAL-OIL,CRANKS (ZD30DDTI) |
| Nissan | Patrol (Y61) | All Engines | 2006 - 2006 | SEAL-OIL,CRANKS |
| Nissan | Safari Pick Up (TY61) | 3.0 TD (ZD30DDTI) | 2012 - 2016 | SEAL-OIL,CRANKS (ZD30DDTI) |
| Nissan | Terrano2 (R20) | All Engines | 2002 - 2004 | SEAL-OIL,CRANKS |
| Nissan | Tk55 (TK3) | All Engines | 2011 - 2011 | SEAL-OIL,CRANKS |
| Nissan | Tk55 (TK3) | 3.0 TD (ZD30DDT) | 2011 - 2011 | SEAL-OIL,CRANKS (ZD30DDT) |
| Nissan | Urvan (E25) | 3.0 TD (ZD30DDTI) | 2003 - 2007 | SEAL-OIL,CRANKS (ZD30DDTI) |
| Nissan | Urvan (E25) | 3.0 D (ZD30DD) | 2001 - 2007 | SEAL-OIL,CRANKS (ZD30DD) |
| Nissan | Urvan (E25) | All Engines | 2001 - 2007 | SEAL-OIL,CRANKS |
Inquire About This Part
Not sure if this fits? Send us your VIN number and we will double check for you.
