TOYOTA 45046-69205 Tie Rod End
Genuine part. Fitment information is for reference only. To ensure 100% compatibility, please send us a message with your VIN number before ordering.
Categories
OEM / Alternate Numbers
Product Description
This genuine OEM TOYOTA (OEM: 45046-69205) tie rod end sub-assembly (END SUB-ASSY, TIE ROD) ensures exceptional durability and a precise fit within the vehicle's steering system. The tie rod end is a vital safety component connecting the steering gear to the wheel hub, enabling accurate wheel turning and unobstructed suspension travel.
Function and Importance
The tie rod end is responsible for transmitting steering forces from the steering gear to the wheel hub. Since the suspension is in constant motion depending on road conditions, the ball joint design provides the necessary flexibility and multi-directional articulation. The OEM-quality component guarantees the preservation of factory steering characteristics and vehicle stability.
Common Symptoms of Wear or Failure
- Loose, imprecise steering response or excessive free play in the steering wheel.
- Clunking, metallic knocking noises from the suspension, especially over uneven surfaces or during cornering.
- Abnormal, uneven tire wear.
- The vehicle pulls to one side while driving straight.
Technical Specifications
- Manufacturer: TOYOTA (Original Equipment Manufacturer)
- Installation Position: Front axle, outer tie rod
- Material: High-strength forged steel alloy for maximum tensile strength
- Protection: Premium-grade, wear-resistant rubber dust boot protecting the ball joint against water and dirt ingress
- Lubrication: Factory pre-packed with durable, high-pressure grease
Vehicle Compatibility
This part conforms strictly to factory specifications and is exclusively compatible with the following models:
- Toyota Land Cruiser 100 (FZJ100)
- Toyota Land Cruiser 100 (HDJ100)
Technical Specifications
| Brand | TOYOTA |
|---|---|
| Weight | 0.985 kg |
Compatible Vehicles
| Make | Model | Engine | Year | Notes |
|---|---|---|---|---|
| Toyota | Land Cruiser 100 (J100) | 4.2 TD (1HDFTE) | 2002 - ... | LINK ASSY, POWER STEERING (HDJ101, 1HDFTE) |
| Toyota | Land Cruiser 100 (J100) | 4.5 (1FZFE) | 2002 - ... | LINK ASSY, POWER STEERING (FZJ100, 1FZFE) |
| Toyota | Land Cruiser 100 (J100) | 4.7 (2UZFE) | 2002 - ... | LINK ASSY, POWER STEERING (UZJ100, 2UZFE) |
| Toyota | Lexus LX (J100) | 4.7 (2UZFE) | 2002 - ... | LINK ASSY, POWER STEERING (UZJ100, 2UZFE) |
Inquire About This Part
Not sure if this fits? Send us your VIN number and we will double check for you.
