TOYOTA 48815-26020 Stabilizer Bar Bushing
Genuine part. Fitment information is for reference only. To ensure 100% compatibility, please send us a message with your VIN number before ordering.
Categories
Product Description
This genuine TOYOTA stabilizer bushing, part number 48815-26020 (factory designation: BUSH STABILIZER), is a premium-quality OEM replacement component essential for the proper operation of the vehicle's suspension system and for ensuring stable road handling.
Function and Operation
The primary function of the stabilizer bushing is to provide a flexible yet secure mounting point between the stabilizer bar and the vehicle body (or subframe). During cornering, the stabilizer bar twists to reduce body roll. The bushings ensure this movement remains controlled while absorbing road vibrations and harshness, preventing them from transferring into the passenger cabin.
Technical Specifications
- Manufacturer: TOYOTA (Original Equipment Manufacturer)
- Part Number: 48815-26020
- Material Composition: Specially formulated, high-density vulcanized rubber compound offering excellent elasticity and high tensile strength. Highly resistant to environmental influences (moisture, mud, road salt) and lubricants.
- Design: Manufactured using precision molding technology for an exact fit to the stabilizer bar diameter, preventing unwanted play.
Common Symptoms of Wear
Stabilizer bushings are subject to continuous mechanical stress and environmental exposure, causing them to age, harden, or tear over time. Common signs of failure include:
- Knocking, rattling, or squeaking noises from the suspension, particularly when driving over uneven roads or speed bumps.
- Less precise steering response and increased instability during cornering.
- Visible cracks, structural deterioration, or deformation of the bushing upon visual inspection.
To ensure safe operation and protect adjacent suspension components, it is recommended to replace worn bushings in pairs (on both sides of the axle).
Technical Specifications
| Brand | TOYOTA |
|---|---|
| Weight | 0.045 kg |
Compatible Vehicles
| Make | Model | Engine | Year | Notes |
|---|---|---|---|---|
| Toyota | Dyna / Toyoace (U100/U200/Y100) | All Engines | 1995 - ... | BUSH, FRONT STABILIZER BAR, NO.1 |
| Toyota | Dyna / Toyoace (U60-U90/Y50-Y80) | All Engines | 1985 - 1995 | BUSH, FRONT STABILIZER BAR, NO.1 |
| Toyota | Hiace (H100) | All Engines | 1995 - 1996 | BUSH, FRONT STABILIZER BAR, NO.1 |
| Toyota | Hiace (H50-H90) | All Engines | 1982 - 1995 | BUSH, FRONT STABILIZER BAR, NO.1 |
| Toyota | Land Cruiser 100 (J100) | 4.5 (1FZFE) | 1998 - ... | BUSH, FRONT STABILIZER BAR, NO.1 (FZJ105, 1FZFE) |
| Toyota | Land Cruiser 70 (J70) | 4.2 D (1HZ) | 1990 - 1991 | BUSH, FRONT STABILIZER BAR, NO.1 (HZJ77, 1HZ) |
| Toyota | Land Cruiser 70 (J70) | 4.5 (1FZF) | 1991 - 1994 | BUSH, FRONT STABILIZER BAR, NO.1 (FZJ75, 1FZF) |
| Toyota | Land Cruiser 70 (J70) | 3.0 TD (1KZT) | 1993 - 1996 | BUSH, FRONT STABILIZER BAR, NO.1 (KZJ78, 1KZT) |
| Toyota | Land Cruiser 70 (J70) | 4.2 TD (1HDFTE) | 1999 - 2007 | BUSH, FRONT STABILIZER BAR, NO.1 (HDJ78, 1HDFTE) |
| Toyota | Land Cruiser 70 (J70) | 4.0 (1GRFE) | 2007 - ... | BUSH, FRONT STABILIZER BAR, NO.1 (GRJ78, 1GRFE) |
| Toyota | Land Cruiser 70 (J70) | 3.4 TD (13BT) | 2016 - 2016 | BUSH, FRONT STABILIZER BAR, NO.1 (TJ0000, 13BT) |
| Toyota | Land Cruiser 80 (J80) | 4.5 (1FZF) | 1992 - ... | BUSH, FRONT STABILIZER BAR, NO.1 (FZJ80, 1FZF) |
| Toyota | Lexus LX (J80) | 4.5 (1FZFE) | 1995 - 1998 | BUSH, FRONT STABILIZER BAR, NO.1 (FZJ80, 1FZFE) |
| Toyota | Quick Delivery (BU68) | All Engines | 1995 - 9999 | BUSH, FRONT STABILIZER BAR, NO.1 |
Inquire About This Part
Not sure if this fits? Send us your VIN number and we will double check for you.
