TOYOTA 52205-60010 Body Mount Cushion Sub-Assembly
Genuine part. Fitment information is for reference only. To ensure 100% compatibility, please send us a message with your VIN number before ordering.
Categories
Product Description
The genuine OEM Toyota 52205-60010 body mount cushion sub-assembly is a high-durability, precision-engineered component responsible for the flexible yet stable connection between the vehicle body and the chassis frame on body-on-frame vehicles.
Key Functions and Operating Principle
This cushion plays a vital role in isolating and absorbing road shocks, vibrations, and structural noise (NVH – Noise, Vibration, Harshness) during driving. It prevents direct metal-to-metal contact, thereby protecting the body structure from fatigue cracking and significantly enhancing passenger cabin comfort.
Technical Specifications and Material Composition
- Material: Specialized, high-density vulcanized elastomer (rubber) compound offering outstanding resistance to dynamic loads, ozone, road salt, and temperature fluctuations.
- Construction: Features an integrated metal inner sleeve that ensures accurate mounting bolt alignment and prevents over-compression of the rubber during installation.
- Mounting Position: Body and chassis frame mounting points.
Common Symptoms of Wear and Failure
Body mount cushions are subject to constant loads and environmental exposure, leading to degradation over time. Common symptoms of failure include:
- Visibly apparent cracks, crumbling, or complete deterioration of the rubber (hardening or softening).
- Knocking, metallic, or squeaking noises when driving over uneven road surfaces or cornering.
- Increased cabin vibration and road noise.
- Altered body-to-chassis panel gaps or misalignment.
To ensure maximum safety and maintain factory ride comfort, replacing worn cushions in pairs or as a complete set is recommended.
Technical Specifications
| Brand | TOYOTA |
|---|---|
| Weight | 0.160 kg |
Compatible Vehicles
| Make | Model | Engine | Year | Notes |
|---|---|---|---|---|
| Toyota | Land Cruiser 80 (J80) | 4.0 (3FE) | 1990 - 1998 | CUSHIION SUB-ASSY, CAB MOUNTING, NO.3 UPPER (FJ80, 3FE) |
| Toyota | Land Cruiser 80 (J80) | 4.5 (1FZF) | 1992 - 9999 | CUSHIION SUB-ASSY, CAB MOUNTING, NO.3 UPPER (FZJ80, 1FZF) |
| Toyota | Lexus LX (J80) | 4.5 (1FZFE) | 1995 - 1998 | CUSHIION SUB-ASSY, CAB MOUNTING, NO.3 UPPER (FZJ80, 1FZFE) |
