TOYOTA 52209-60050 Body Mount Cushion Sub-Assembly
Genuine part. Fitment information is for reference only. To ensure 100% compatibility, please send us a message with your VIN number before ordering.
Categories
Product Description
The genuine TOYOTA 52209-60050 (Body Mount Cushion Sub-Assembly) is a premium-quality, original equipment manufacturer (OEM) part that plays a critical role in providing a flexible yet stable connection between the vehicle body and chassis. This component is specifically engineered to absorb road shocks, vibrations, and noise, thereby ensuring maximum ride comfort and protecting the structural integrity of the vehicle body.
Function and Importance
The primary function of the body mount cushion sub-assembly is vibration dampening and noise isolation (reducing NVH – Noise, Vibration, and Harshness). In body-on-frame vehicles, it minimizes mechanical stress at the mounting points by preventing direct metal-to-metal contact. Genuine Toyota parts are manufactured from high-grade, age-resistant rubber compounds with an integrated metal sleeve, providing superior resistance to environmental factors (moisture, mud, road salts, temperature fluctuations) and continuous mechanical loads.
Symptoms of Wear and Failure
Over time, constant loading and environmental exposure can cause the rubber material to age, harden, crack, or completely deteriorate. A worn body mount cushion may exhibit the following symptoms:
- Metallic clunking, knocking, or squeaking noises when driving over rough road surfaces or during cornering.
- Increased vibration and noise levels inside the cabin.
- Slight shifting, movement, or tilting of the body relative to the chassis.
- Visibly identifiable cracks, deformation, or separation of the rubber from the internal metal sleeve upon inspection.
Technical Specifications
- Manufacturer: TOYOTA (Original OEM)
- Part Number: 52209-60050
- Part Type: Body Mount Cushion Sub-Assembly
- Material: High-tensile vulcanized elastomer (rubber) with steel reinforcing/guide sleeve
- Mounting Location: Body and chassis mounting points
- Durability: Excellent resistance to ozone, oil, and heat for extended service life
Technical Specifications
| Brand | TOYOTA |
|---|---|
| Weight | 0.060 kg |
Compatible Vehicles
| Make | Model | Engine | Year | Notes |
|---|---|---|---|---|
| Toyota | Land Cruiser 80 (J80) | 4.0 (3FE) | 1990 - 1998 | CUSHION SUB-ASSY, REAR END BODY MOUNTING, UPPER (FJ80, 3FE) |
| Toyota | Land Cruiser 80 (J80) | 4.5 (1FZF) | 1992 - 9999 | CUSHION SUB-ASSY, REAR END BODY MOUNTING, UPPER (FZJ80, 1FZF) |
| Toyota | Lexus LX (J80) | 4.5 (1FZFE) | 1995 - 1998 | CUSHION SUB-ASSY, REAR END BODY MOUNTING, UPPER (FZJ80, 1FZFE) |
Inquire About This Part
Not sure if this fits? Send us your VIN number and we will double check for you.
