NISSAN 11110-VC200 Engine Oil Pan Assembly

The genuine NISSAN part number 11110-VC200 oil pan assembly (PAN ASSY OIL) is an essential structural component of the engine lubrication system. Fastened to the lower surface of the engine block, it provides safe storage for engine oil while facilitating the circulation and cooling required to maintain the lubrication cycle. The precise OEM design ensures a perfect fit, a leak-free seal, and accurate positioning for the factory oil dipstick and oil pump pickup tube.

Technical Specifications:

• Part Name: Oil Pan Assembly (PAN ASSY OIL)
• Manufacturer: NISSAN (Genuine OEM part)
• Part Number (SKU): 11110-VC200
• Replacement / OEM Reference Number: 11111VB000
• Mounting Position: Lower section of the engine block
• Purpose: Engine oil storage, cooling, and recirculation
• Features: Factory mounting points, drain plug hole, corrosion-resistant finish

Common Failures and Reasons for Replacement:

Due to its exposed position, the oil pan is highly susceptible to bottom-side mechanical impacts (such as off-road impacts and stone chips). Deformation, cracking, or stripped drain plug threads from overtightening can result in oil leakage, leading to low oil levels and catastrophic engine lubrication failure. In the event of damage, installing a genuine factory-specification replacement is essential to restoring reliable operation.

Vehicle Compatibility:

• Nissan Patrol (Y61) 4.5 [2001 - 2011] (PAN ASSY OIL (TB45E))
• Nissan Patrol (Y61) 4.8 [2001 - 2012] (PAN ASSY OIL (TB48DE))
• Nissan Patrol (Y61) 4.5 [2001 - 2003] (PAN ASSY OIL (TB45S))
• Nissan Safari (GCY61) 4.8 [2017 - 2017] (PAN ASSY OIL (TB48DE))
• Nissan Safari Pick Up (GCTY61) 4.8 [2017 - 2017] (PAN ASSY OIL (TB48DE))
• Nissan Safari Pick Up (TY61) [2004 - 2012] (PAN ASSY OIL)
