TOYOTA 04474-35100 Rear Drum Brake Wheel Cylinder Repair Kit
Genuine part. Fitment information is for reference only. To ensure 100% compatibility, please send us a message with your VIN number before ordering.
Categories
OEM / Alternate Numbers
Product Description
The genuine OEM part Toyota 04474-35100 is a repair kit designed for rebuilding the hydraulic rear wheel brake cylinder of drum brakes. The kit contains essential wear parts that ensure proper sealing and protection for the wheel cylinder, including brake fluid-resistant seal cups, piston dust boots, and internal expanders.
Function and Importance:
In a drum brake system, the wheel cylinder is responsible for converting hydraulic pressure into mechanical force, pressing the brake shoes against the brake drum surface. Aged, hardened, or cracked rubber seals cause brake fluid leaks, which lead to a severe drop in braking efficiency, contamination of the brake shoes, and extended pedal travel due to air entering the system. Installing this rebuild kit restores the cylinder's factory sealing integrity and dependable operation.
Technical Specifications:
- Part Type: Rear wheel cylinder repair kit (for drum brake)
- Fitting Position: Rear axle, left/right wheel hub
- Material: Premium EPDM elastomer resistant to brake fluid (DOT3, DOT4, DOT5.1) and corrosion-protected metal components
- OEM Part Number: 04474-35100
- Alternative / Superseded Part Number: 04474-60010
- Manufacturer: Toyota
Compatible Vehicles:
- Toyota 4Runner (N180) 3.4 [1995 - 2000] (VZN180, 5VZFE)
- Toyota 4Runner (N180) 2.7 [1995 - 1996] (RZN185, 3RZFE)
- Toyota 4Runner (N180) 3.0 D-4D [1995 - ...] (KDN185, 1KDFTV)
- Toyota 4Runner (N180) 3.0 TD [1995 - ...] (KZN185, 1KZT)
- Toyota Hiace (H50-H90) [1986 - 1989]
- Toyota Hiace (H100) [1989 - 2004]
- Toyota Hiace (H200) 2.5 D-4D [2012 - 2014] (KDH222, 2KDFTV)
- Toyota Hiace (H200) 2.7 [2013 - ...] (TRH223, 2TRFE)
- Toyota Land Cruiser 40 (J40) [1980 - 1984] (BJ40)
- Toyota Land Cruiser 60 (J60) 4.0 [1980 - 1992] (BJ60, 3FE)
- Toyota Land Cruiser 70 (J70) 3.4 TD [1984 - 1990] (BJ70, 13BT)
- Toyota Land Cruiser 70 (J70) 4.2 D [1990 - 1993] (FJ75, 1HZ)
- Toyota Land Cruiser 70 (J70) 4.5 [1992 - 1993] (FJ70, 1FZF)
- Toyota Land Cruiser 70 (J70) 3.5 D [1993 - 1994] (PZJ70, 1PZ)
- Toyota Land Cruiser 70 (J70) 3.0 TD [1995 - 1996] (KZJ70, 1KZT)
- Toyota Land Cruiser 70 (J70) 4.5 D-4D [2007 - 2012] (VDJ70, 1VDFTV)
- Toyota Land Cruiser 70 (J70) 4.0 [2007 - 2014] (GRJ79, 1GRFE)
- Toyota Land Cruiser 80 (J80) 4.5 [1990 - 1996] (FZJ80, 1FZF)
- Toyota Land Cruiser 80 (J80) 4.2 TD [1990 - 1992] (HDJ80, 1HDFT)
- Toyota Land Cruiser 80 (J80) 4.0 [1990 - 1995] (FJ80, 3FE)
- Toyota Land Cruiser 80 (J80) 4.2 D [1992 - 1999] (HZJ80, 1HZ)
- Toyota Land Cruiser 100 (J100) 4.2 D [1998 - 2005] (HZJ105, 1HZ)
- Toyota Land Cruiser 100 (J100) 4.5 [2005 - ...] (FZJ100, 1FZFE)
- Toyota Land Cruiser Prado (J90) 3.0 TD [1996 - ...] (KZJ90, 1KZT)
- Toyota Land Cruiser Prado (J90) 2.7 [1998 - 1999] (RZJ90, 3RZF)
- Toyota T100 (RCK10) [1992 - ...]
- Toyota Tundra (GSK30) [1999 - ...]
Technical Specifications
| Brand | TOYOTA |
|---|---|
| Weight | 0.115 kg |
Compatible Vehicles
| Make | Model | Engine | Year | Notes |
|---|---|---|---|---|
| Toyota | 4Runner (N180) | 3.4 (5VZFE) | 1995 - 2000 | CYLINDER KIT, REAR WHEEL (VZN180, 5VZFE) |
| Toyota | 4Runner (N180) | 2.7 (3RZFE) | 1995 - 1996 | CYLINDER KIT, REAR WHEEL (RZN185, 3RZFE) |
| Toyota | 4Runner (N180) | 3.0 D-4D (1KDFTV) | 1995 - 9999 | CYLINDER KIT, REAR WHEEL (KDN185, 1KDFTV) |
| Toyota | 4Runner (N180) | 3.0 TD (1KZT) | 1995 - ... | CYLINDER KIT, REAR WHEEL (KZN185, 1KZT) |
| Toyota | Hiace (H100) | All Engines | 1989 - 2004 | CYLINDER KIT, REAR WHEEL |
| Toyota | Hiace (H200) | 2.5 D-4D (2KDFTV) | 2012 - 2014 | CYLINDER KIT, REAR WHEEL (KDH222, 2KDFTV) |
| Toyota | Hiace (H200) | 2.7 (2TRFE) | 2013 - ... | CYLINDER KIT, REAR WHEEL (TRH223, 2TRFE) |
| Toyota | Hiace (H50-H90) | All Engines | 1986 - 1989 | CYLINDER KIT, REAR WHEEL |
| Toyota | Land Cruiser 100 (J100) | 4.2 D (1HZ) | 1998 - 2005 | CYLINDER KIT, REAR WHEEL (HZJ105, 1HZ) |
| Toyota | Land Cruiser 100 (J100) | 4.5 (1FZFE) | 2005 - 9999 | CYLINDER KIT, REAR WHEEL (FZJ100, 1FZFE) |
| Toyota | Land Cruiser 40 (J40) | All Engines | 1980 - 1984 | CYLINDER KIT, REAR WHEEL (BJ40) |
| Toyota | Land Cruiser 60 (J60) | 4.0 (3FE) | 1980 - 1992 | CYLINDER KIT, REAR WHEEL (BJ60, 3FE) |
| Toyota | Land Cruiser 70 (J70) | 3.4 TD (13BT) | 1984 - 1990 | CYLINDER KIT, REAR WHEEL (BJ70, 13BT) |
| Toyota | Land Cruiser 70 (J70) | 4.2 D (1HZ) | 1990 - 1993 | CYLINDER KIT, REAR WHEEL (FJ75, 1HZ) |
| Toyota | Land Cruiser 70 (J70) | 4.5 (1FZF) | 1992 - 1993 | CYLINDER KIT, REAR WHEEL (FJ70, 1FZF) |
| Toyota | Land Cruiser 70 (J70) | 3.5 D (1PZ) | 1993 - 1994 | CYLINDER KIT, REAR WHEEL (PZJ70, 1PZ) |
| Toyota | Land Cruiser 70 (J70) | 3.0 TD (1KZT) | 1995 - 1996 | CYLINDER KIT, REAR WHEEL (KZJ70, 1KZT) |
| Toyota | Land Cruiser 70 (J70) | 4.5 D-4D (1VDFTV) | 2007 - 2012 | CYLINDER KIT, REAR WHEEL (VDJ70, 1VDFTV) |
| Toyota | Land Cruiser 70 (J70) | 4.0 (1GRFE) | 2007 - 2014 | CYLINDER KIT, REAR WHEEL (GRJ79, 1GRFE) |
| Toyota | Land Cruiser 80 (J80) | 4.5 (1FZF) | 1990 - 1996 | CYLINDER KIT, REAR WHEEL (FZJ80, 1FZF) |
| Toyota | Land Cruiser 80 (J80) | 4.2 TD (1HDFT) | 1990 - 1992 | CYLINDER KIT, REAR WHEEL (HDJ80, 1HDFT) |
| Toyota | Land Cruiser 80 (J80) | 4.0 (3FE) | 1990 - 1995 | CYLINDER KIT, REAR WHEEL (FJ80, 3FE) |
| Toyota | Land Cruiser 80 (J80) | 4.2 D (1HZ) | 1992 - 1999 | CYLINDER KIT, REAR WHEEL (HZJ80, 1HZ) |
| Toyota | Land Cruiser Prado (J90) | 3.0 TD (1KZT) | 1996 - ... | CYLINDER KIT, REAR WHEEL (KZJ90, 1KZT) |
| Toyota | Land Cruiser Prado (J90) | 2.7 (3RZF) | 1998 - 1999 | CYLINDER KIT, REAR WHEEL (RZJ90, 3RZF) |
| Toyota | T100 (RCK10) | All Engines | 1992 - ... | CYLINDER KIT, REAR WHEEL |
| Toyota | Tundra (GSK30) | All Engines | 1999 - ... | CYLINDER KIT, REAR WHEEL |
Inquire About This Part
Not sure if this fits? Send us your VIN number and we will double check for you.
