TOYOTA 13540-17011 Timing Belt Tensioner Assembly
Genuine part. Fitment information is for reference only. To ensure 100% compatibility, please send us a message with your VIN number before ordering.
OEM / Alternate Numbers
Product Description
The genuine Toyota (OEM) tensioner assembly (tensioner cartridge) with part number 13540-17011 ensures reliable and accurate timing system operation in Toyota's legendary inline-six diesel engines (1HZ, 1HD-FT, 1HD-FTE). This automatic tensioner unit maintains constant, dynamically compensated timing belt tension across the entire engine speed and temperature range. The cartridge prevents belt slack and slapping while damping dynamic vibrations during engine operation, avoiding timing slippage and premature belt tooth wear.
Wear, hydraulic fluid loss, or internal fatigue of the tensioner cartridge can cause metallic rattling noises at start-up and idle, irregular valve timing phases, and in the worst case, belt jumping that results in catastrophic engine failure. Following factory service guidelines, replacing the tensioner cartridge during complete timing system maintenance is strongly recommended.
Technical specifications and references:
- Manufacturer: TOYOTA (Genuine OEM part)
- Part Number: 13540-17011
- Superseded / OEM Reference Numbers: 13540-17010 (1354017010)
- Part Type: Hydraulic/mechanical tensioner assembly (Tensioner Assy, Timing/Chain No.1)
- Compatible Engine Types: Toyota 4.2 D and 4.2 TD (1HZ, 1HD-FT, 1HD-FTE)
Compatible Vehicles:
- Toyota Coaster (B40/B50) 4.2 TD [1995 - 1997] (1HDFT)
- Toyota Coaster (B40/B50) 4.2 D [1997 - ...] (1HZ)
- Toyota Coaster (B60/B70) 4.2 D [2017 - ...] (1HZ)
- Toyota Land Cruiser 100 (J100) 4.2 TD [1998 - ...] (HDJ100, 1HDFTE)
- Toyota Land Cruiser 100 (J100) 4.2 D [1998 - 2002] (HDJ100, 1HZ)
- Toyota Land Cruiser 70 (J70) 4.2 D [1998 - 1999] (HZJ75, 1HZ)
- Toyota Land Cruiser 80 (J80) 4.2 TD [1995 - 1998] (HDJ81, 1HDFT)
Technical Specifications
| Brand | TOYOTA |
|---|---|
| Weight | 0.160 kg |
Compatible Vehicles
| Make | Model | Engine | Year | Notes |
|---|---|---|---|---|
| Toyota | Coaster (B40/B50) | 4.2 TD (1HDFT) | 1995 - 1997 | TENSIONER ASSY, CHAIN, NO.1 (1HDFT) |
| Toyota | Coaster (B40/B50) | 4.2 D (1HZ) | 1997 - ... | TENSIONER ASSY, CHAIN, NO.1 (1HZ) |
| Toyota | Coaster (B60/B70) | 4.2 D (1HZ) | 2017 - 9999 | TENSIONER ASSY, CHAIN, NO.1 (1HZ) |
| Toyota | Land Cruiser 100 (J100) | 4.2 TD (1HDFTE) | 1998 - ... | TENSIONER ASSY, CHAIN, NO.1 (HDJ100, 1HDFTE) |
| Toyota | Land Cruiser 100 (J100) | 4.2 D (1HZ) | 1998 - 2002 | TENSIONER ASSY, CHAIN, NO.1 (HDJ100, 1HZ) |
| Toyota | Land Cruiser 70 (J70) | 4.2 D (1HZ) | 1998 - 1999 | TENSIONER ASSY, CHAIN, NO.1 (HZJ75, 1HZ) |
| Toyota | Land Cruiser 80 (J80) | 4.2 TD (1HDFT) | 1995 - 1998 | TENSIONER ASSY, CHAIN, NO.1 (HDJ81, 1HDFT) |
Inquire About This Part
Not sure if this fits? Send us your VIN number and we will double check for you.
