TOYOTA 13568-09131 Timing Belt

The genuine Toyota timing belt with part number 13568-09131 is a vital component of the engine timing system, responsible for maintaining synchronized drive transfer between the crankshaft and the camshaft. Its precise fit and durable tooth profile ensure flawless valve opening and closing timing. Because D-4D engines feature an interference design, timing belt wear, tooth stripping, or belt breakage can cause severe internal engine damage through piston-to-valve contact. The premium wear- and heat-resistant synthetic rubber compound ensures a long service life and quiet operation even under extreme operating conditions.

Technical Specifications and References

• Manufacturer: TOYOTA (Genuine OEM part)
• Part Number: 13568-09131
• OEM and Replacement Reference Numbers: 1356839016, 1356809130
• Compatible Engine Codes: 1KD-FTV (3.0 D-4D), 2KD-FTV (2.5 D-4D)
• Material Construction: Heat-, ozone-, and oil-resistant HNBR elastomer reinforced with high-tensile cords
• Part Type: Toothed timing belt

Vehicle Compatibility

• Toyota 4Runner (N180) 3.0 D-4D [2000 - 9999] (KDN185, 1KDFTV)
• Toyota 4Runner (N210) 3.0 D-4D [2002 - 9999] (KDN215, 1KDFTV)
• Toyota Dyna / Toyoace (U300/U400/Y200) 3.0 D-4D [2010 - 9999] (1KDFTV)
• Toyota Fortuner (GGN50) 3.0 D-4D [2005 - 2006] (KUN51, 1KDFTV)
• Toyota Fortuner (GGN50) 2.5 D-4D [2010 - 2010] (KUN60, 2KDFTV)
• Toyota Hiace (H200) 2.5 D-4D [2005 - 2007] (KDH212, 2KDFTV)
• Toyota Hiace (H200) 3.0 D-4D [2010 - 2017] (KDH200, 1KDFTV)
• Toyota Hiace S.B.V. / Granvia (XH10/XH20) 2.5 D-4D [2010 - 9999] (2KDFTV)
• Toyota Hilux (N10/N20/N30) 3.0 D-4D [2004 - 2006] (KUN10, 1KDFTV)
• Toyota Hilux (N10/N20/N30) 2.5 D-4D [2005 - ...] (KUN25, 2KDFTV)
• Toyota Hilux (N140-N170) 3.0 D-4D [2004 - 2005] (KDN145, 1KDFTV)
• Toyota Hilux (N140-N170) 2.5 D-4D [2001 - 9999] (KDN145, 2KDFTV)
• Toyota Innova / Kijang (AN40) 2.5 D-4D [2004 - ...] (KUN40, 2KDFTV)
• Toyota Land Cruiser Prado (J150) 3.0 D-4D [2010 - ...] (KDJ150, 1KDFTV)
• Toyota Land Cruiser Prado (J120) 3.0 D-4D [2002 - ...] (KDJ120, 1KDFTV)
• Toyota Land Cruiser Prado (J90) 3.0 D-4D [2000 - 2002] (KDJ90, 1KDFTV)

Maintenance and Symptoms of Wear

The timing belt has a finite operating lifespan and must be replaced at the mileage or time intervals specified by the vehicle manufacturer. Typical symptoms of wear include micro-cracking at the base of the teeth, fraying of the fabric layer, glazing on the belt backing, or softening due to oil contamination. As a preventative measure, it is recommended to replace the tensioner and idler pulleys together with the timing belt.
