TOYOTA
13568-39016
TOYOTA 13568-39016 Timing Belt
74.50 EUR
58.60 EUR + 15.90 EUR VAT
Hurry, only 3 left in stock!
Genuine part. Fitment information is for reference only. To ensure 100% compatibility, please send us a message with your VIN number before ordering.
OEM / Alternate Numbers
In Stock & Ready to Ship
Genuine Quality
Secure Checkout
Product Description
The genuine Toyota timing belt with part number 13568-39016 is a critical component of the engine timing system. Its function is to maintain precise mechanical synchronization between the crankshaft and the camshaft, ensuring the accurate, timed opening and closing of the intake and exhaust valves relative to piston movement. In modern direct-injection diesel engines (1KD-FTV and 2KD-FTV), loss of synchronization or belt failure can cause contact between the pistons and valves, resulting in catastrophic engine damage.
Technical Specifications and Features
- OEM Part Number: 13568-39016
- Superseded / Alternative Reference Numbers: 13568-09131, 13568-39015
- Material Construction: High heat- and oil-resistant HNBR synthetic elastomer rubber with wear-resistant fabric-faced teeth
- Tensile Cord Core: High tensile strength embedded fiberglass cords engineered for minimal stretch
- Signs of Wear: Surface micro-cracks at the tooth roots or belt back, tooth wear, fraying fabric fibers, structural elongation, or unusual bearing/whirring noises from beneath the timing cover
Vehicle Compatibility
- Toyota 4Runner (N180) 3.0 D-4D [2000 - 9999] (KDN185, 1KDFTV)
- Toyota 4Runner (N210) 3.0 D-4D [2002 - 9999] (KDN215, 1KDFTV)
- Toyota Dyna / Toyoace (U300/U400/Y200) 3.0 D-4D [2010 - 9999] (1KDFTV)
- Toyota Fortuner (GGN50) 3.0 D-4D [2005 - 2006] (KUN51, 1KDFTV)
- Toyota Fortuner (GGN50) 2.5 D-4D [2010 - 2010] (KUN60, 2KDFTV)
- Toyota Hiace (H200) 2.5 D-4D [2005 - 2007] (KDH212, 2KDFTV)
- Toyota Hiace (H200) 3.0 D-4D [2010 - 2017] (KDH200, 1KDFTV)
- Toyota Hiace S.B.V. / Granvia (XH10/XH20) 2.5 D-4D [2010 - 9999] (2KDFTV)
- Toyota Hilux (N10/N20/N30) 3.0 D-4D [2004 - 2006] (KUN10, 1KDFTV)
- Toyota Hilux (N10/N20/N30) 2.5 D-4D [2005 - ...] (KUN25, 2KDFTV)
- Toyota Hilux (N140-N170) 3.0 D-4D [2004 - 2005] (KDN145, 1KDFTV)
- Toyota Hilux (N140-N170) 2.5 D-4D [2001 - 9999] (KDN145, 2KDFTV)
- Toyota Innova / Kijang (AN40) 2.5 D-4D [2004 - ...] (KUN40, 2KDFTV)
- Toyota Land Cruiser Prado (J90) 3.0 D-4D [2000 - 2002] (KDJ90, 1KDFTV)
- Toyota Land Cruiser Prado (J120) 3.0 D-4D [2002 - ...] (KDJ120, 1KDFTV)
- Toyota Land Cruiser Prado (J150) 3.0 D-4D [2010 - ...] (KDJ150, 1KDFTV)
Technical Specifications
| Brand | TOYOTA |
|---|---|
| Weight | 0.110 kg |
Compatible Vehicles
Genuine part. Fitment information is for reference only. To ensure 100% compatibility, please send us a message with your VIN number before ordering.
| Make | Model | Engine | Year | Notes |
|---|---|---|---|---|
| Toyota | 4Runner (N180) | 3.0 D-4D (1KDFTV) | 2000 - 9999 | BELT, TIMING (KDN185, 1KDFTV) |
| Toyota | 4Runner (N210) | 3.0 D-4D (1KDFTV) | 2002 - 9999 | BELT, TIMING (KDN215, 1KDFTV) |
| Toyota | Dyna / Toyoace (U300/U400/Y200) | 3.0 D-4D (1KDFTV) | 2010 - 9999 | BELT, TIMING (1KDFTV) |
| Toyota | Fortuner (GGN50) | 3.0 D-4D (1KDFTV) | 2005 - 2006 | BELT, TIMING (KUN51, 1KDFTV) |
| Toyota | Fortuner (GGN50) | 2.5 D-4D (2KDFTV) | 2010 - 2010 | BELT, TIMING (KUN60, 2KDFTV) |
| Toyota | Hiace (H200) | 2.5 D-4D (2KDFTV) | 2005 - 2007 | BELT, TIMING (KDH212, 2KDFTV) |
| Toyota | Hiace (H200) | 3.0 D-4D (1KDFTV) | 2010 - 2017 | BELT, TIMING (KDH200, 1KDFTV) |
| Toyota | Hiace S.B.V. / Granvia (XH10/XH20) | 2.5 D-4D (2KDFTV) | 2010 - 9999 | BELT, TIMING (2KDFTV) |
| Toyota | Hilux (N10/N20/N30) | 3.0 D-4D (1KDFTV) | 2004 - 2006 | BELT, TIMING (KUN10, 1KDFTV) |
| Toyota | Hilux (N10/N20/N30) | 2.5 D-4D (2KDFTV) | 2005 - ... | BELT, TIMING (KUN25, 2KDFTV) |
| Toyota | Hilux (N140-N170) | 3.0 D-4D (1KDFTV) | 2004 - 2005 | BELT, TIMING (KDN145, 1KDFTV) |
| Toyota | Hilux (N140-N170) | 2.5 D-4D (2KDFTV) | 2001 - 9999 | BELT, TIMING (KDN145, 2KDFTV) |
| Toyota | Innova / Kijang (AN40) | 2.5 D-4D (2KDFTV) | 2004 - ... | BELT, TIMING (KUN40, 2KDFTV) |
| Toyota | Land Cruiser Prado (J150) | 3.0 D-4D (1KDFTV) | 2010 - ... | BELT, TIMING (KDJ150, 1KDFTV) |
| Toyota | Land Cruiser Prado (J120) | 3.0 D-4D (1KDFTV) | 2002 - ... | BELT, TIMING (KDJ120, 1KDFTV) |
| Toyota | Land Cruiser Prado (J90) | 3.0 D-4D (1KDFTV) | 2000 - 2002 | BELT, TIMING (KDJ90, 1KDFTV) |
Inquire About This Part
Not sure if this fits? Send us your VIN number and we will double check for you.
