TOYOTA 17377-88410 Turbocharger Air Tube Gasket
Genuine part. Fitment information is for reference only. To ensure 100% compatibility, please send us a message with your VIN number before ordering.
Categories
Product Description
The genuine OEM Toyota 17377-88410 air tube gasket (GASKET, AIR TUBE, NO.2) is a critical sealing component of the forced induction and intake system. Its primary role is to provide an airtight seal at the joints between the turbocharger, charge air pipes, and the intake manifold. A hermetic seal is essential for maintaining optimal boost pressure, preventing boost leaks, and keeping unfiltered ambient air and foreign contaminants from entering the engine.
Aging, cracking, or deformation of the gasket can lead to loss of boost pressure, audible whistling or hissing sounds under load, elevated fuel consumption, and air-fuel mixture diagnostic trouble codes recorded by the engine control unit. Gasket replacement is strongly recommended whenever the turbocharger or intake ducting is serviced or disassembled.
Technical Specifications:
- Part Number (OEM): 17377-88410
- Manufacturer: TOYOTA Genuine Parts
- Part Designation: Air Tube / Turbo Pipe Gasket (Gasket, Air Tube No. 2)
- Installation Position: Turbocharger air tube connection
- Material: High heat- and oil-resistant metallic / composite sealing material
Vehicle Compatibility:
- Toyota Coaster (B40/B50) 4.1 D [1999 - 2006] (15BF)
- Toyota Coaster (B40/B50) 4.2 TD [1999 - 2004] (1HDFT)
- Toyota Dyna / Toyoace (U100/U200/Y100) 4.1 D [1999 - ...] (15BF)
- Toyota Dyna / Toyoace (U300/U400/Y200) 4.1 TD [1999 - 2007] (15BFTE)
- Toyota Land Cruiser 100 (J100) 4.2 TD [1998 - ...] (HDJ100, 1HDFTE)
- Toyota Land Cruiser 70 (J70) 4.2 TD [2001 - 2007] (HDJ70, 1HDFTE)
- Toyota Mark II / Chaser / Cresta (X100) 2.5 Turbo [1996 - ...] (1JZGTE)
- Toyota Mark II / Chaser / Cresta (X110) 2.5 Turbo [2000 - 2006] (1JZGTE)
- Toyota Mega Cruiser (BXD20) 4.1 TD [1999 - ...] (15BFT)
- Toyota Soarer (JZZ3) 2.5 Turbo [1996 - ...] (1JZGTE)
- Toyota Verossa (GX11) 2.5 Turbo [2001 - 2004] (1JZGTE)
Technical Specifications
| Brand | TOYOTA |
|---|---|
| Weight | 0.010 kg |
Compatible Vehicles
| Make | Model | Engine | Year | Notes |
|---|---|---|---|---|
| Toyota | Coaster (B40/B50) | 4.1 D (15BF) | 1999 - 2006 | GASKET, AIR TUBE, NO.2 (15BF) |
| Toyota | Coaster (B40/B50) | 4.2 TD (1HDFT) | 1999 - 2004 | GASKET, AIR TUBE, NO.2 (1HDFT) |
| Toyota | Dyna / Toyoace (U100/U200/Y100) | 4.1 D (15BF) | 1999 - 9999 | GASKET, AIR TUBE, NO.2 (15BF) |
| Toyota | Dyna / Toyoace (U300/U400/Y200) | 4.1 TD (15BFTE) | 1999 - 2007 | GASKET, AIR TUBE, NO.2 (15BFTE) |
| Toyota | Land Cruiser 100 (J100) | 4.2 TD (1HDFTE) | 1998 - ... | GASKET, AIR TUBE, NO.2 (HDJ100, 1HDFTE) |
| Toyota | Land Cruiser 70 (J70) | 4.2 TD (1HDFTE) | 2001 - 2007 | GASKET, AIR TUBE, NO.2 (HDJ70, 1HDFTE) |
| Toyota | Mark II / Chaser / Cresta (X100) | 2.5 Turbo (1JZGTE) | 1996 - ... | GASKET, AIR TUBE, NO.2 (1JZGTE) |
| Toyota | Mark II / Chaser / Cresta (X110) | 2.5 Turbo (1JZGTE) | 2000 - 2006 | GASKET, AIR TUBE, NO.2 (1JZGTE) |
| Toyota | Mega Cruiser (BXD20) | 4.1 TD (15BFT) | 1999 - 9999 | GASKET, AIR TUBE, NO.2 (15BFT) |
| Toyota | Soarer (JZZ3) | 2.5 Turbo (1JZGTE) | 1996 - 9999 | GASKET, AIR TUBE, NO.2 (1JZGTE) |
| Toyota | Verossa (GX11) | 2.5 Turbo (1JZGTE) | 2001 - 2004 | GASKET, AIR TUBE, NO.2 (1JZGTE) |
Inquire About This Part
Not sure if this fits? Send us your VIN number and we will double check for you.
