TOYOTA 17567-17020 Exhaust Tailpipe Cushion Hanger

The genuine Toyota 17567-17020 exhaust hanger rubber cushion (Cushion, Exhaust Tail Pipe) is designed to provide a secure and flexible mounting for the rear exhaust section to the vehicle chassis. Its primary function is to effectively absorb and isolate mechanical vibrations generated by exhaust gas pulses and engine operation, preventing their direct transfer into the chassis and passenger cabin.

Technical Specifications:

• Part Number: 17567-17020
• Manufacturer: TOYOTA (Genuine OEM)
• Component Type: Exhaust tailpipe hanger rubber / vibration damper
• Mounting Position: Rear exhaust tailpipe section (Tail pipe - rear)
• Material: High heat-resistant, oil- and weather-resistant vulcanized elastomer
• Design: High tensile strength, vibration-absorbing profile

Function and Symptoms of Wear:

Exhaust hanger rubbers are subjected to continuous dynamic loads, extreme temperature cycles, and exposure to environmental elements. Over time, the rubber material can deteriorate, harden, crack, or tear. Common symptoms of a failed exhaust cushion include a sagging exhaust pipe, metallic rattling or clunking sounds from underneath the vehicle over uneven surfaces, and increased cabin vibration. Leaving worn hangers unaddressed can cause fatigue cracking in exhaust pipes and muffler welds.

Vehicle Compatibility:

• Toyota Coaster (B40/B50) 2.7 [2004 - 2007] (CUSHION, EXHAUST TAIL PIPE (FOR REAR) (3RZF))
• Toyota Coaster (B40/B50) 4.1 [2004 - ...] (CUSHION, EXHAUST TAIL PIPE (FOR REAR) (1BZFPE))
• Toyota Coaster (B40/B50) 3.7 D [2004 - ...] (CUSHION, EXHAUST TAIL PIPE (FOR REAR) (14B))
• Toyota Coaster (B40/B50) 4.1 D [2004 - 2006] (CUSHION, EXHAUST TAIL PIPE (FOR REAR) (15BF))
• Toyota Coaster (B60/B70) 4.1 [2017 - ...] (CUSHION, EXHAUST TAIL PIPE (FOR REAR) (1BZFPE))
• Toyota Coaster (B60/B70) 2.7 [2017 - ...] (CUSHION, EXHAUST TAIL PIPE (FOR REAR) (2TRFE))
• Toyota Coaster (B60/B70) 4.2 D [2017 - 9999] (CUSHION, EXHAUST TAIL PIPE (FOR REAR) (1HZ))
• Toyota Coaster (B60/B70) 3.7 D [2017 - 2019] (CUSHION, EXHAUST TAIL PIPE (FOR REAR) (14B))
• Toyota Dyna / Toyoace (U300/U400/Y200) [2000 - 2004] (CUSHION, EXHAUST TAIL PIPE (FOR REAR))
• Toyota Land Cruiser 100 (J100) 4.5 [1999 - ...] (CUSHION, EXHAUST TAIL PIPE (FOR REAR) (FZJ105, 1FZFE))
• Toyota Land Cruiser 70 (J70) 4.2 D [1993 - 1999] (CUSHION, EXHAUST TAIL PIPE (FOR REAR) (HZJ75, 1HZ))
• Toyota Land Cruiser 70 (J70) 4.5 [1999 - 2009] (CUSHION, EXHAUST TAIL PIPE (FOR REAR) (FZJ78, 1FZF))
• Toyota Land Cruiser 70 (J70) 4.5 D-4D [2007 - ...] (CUSHION, EXHAUST TAIL PIPE (FOR REAR) (VDJ70, 1VDFTV))
• Toyota Land Cruiser 70 (J70) 4.0 [2009 - ...] (CUSHION, EXHAUST TAIL PIPE (FOR REAR) (GRJ71, 1GRFE))
