TOYOTA 43204-60032 Front Steering Knuckle Grease Wiper Seal Kit
Genuine part. Fitment information is for reference only. To ensure 100% compatibility, please send us a message with your VIN number before ordering.
OEM / Alternate Numbers
Product Description
The genuine TOYOTA (SKU: 43204-60032) grease wiper seal kit (SEAL SUB-ASSY) is a premium quality, original component designed for sealing the vehicle's front axle steering knuckle (swivel hub). This kit plays a critical role in protecting the front axle drive and steering mechanism by ensuring lubricant retention and keeping out contaminants.
Function and Operating Principle
The grease wiper seal rides on the spherical surface of the steering knuckle (swivel ball). It serves a dual purpose:
- Lubricant retention: Prevents the specialized graphite or lithium grease required to lubricate the CV joint from leaking out of the housing.
- External protection: Creates an effective barrier against water, mud, dust, and other environmental contaminants encountered during off-road and on-road operation.
Technical Characteristics and Construction
Manufactured to strict OEM specifications, this kit is made from high-grade, durable materials resistant to continuous friction, extreme temperature fluctuations, and automotive chemicals (greases, oils).
- Manufacturer: TOYOTA OEM
- OEM Part Number: 43204-60032
- Replacement / Alternative Part Numbers: 43204-60031, 4320460031
- Kit Contents: Specially profiled rubber wiper ring, felt dust seal ring, along with the required split metal retaining rings and fasteners.
- Fitting Position: Front axle, right and left steering knuckle (swivel ball).
Signs of Wear and Failure
The seal is subjected to continuous mechanical wear due to rotational articulation during steering. Seal degradation or damage can result in the following symptoms:
- Grease stains appearing on the knuckle ball surface or on the inner side of the wheel.
- Differential oil mixing with steering knuckle grease (if the inner axle shaft oil seal also fails, thin gear oil washes out grease past the wiper seal).
- Crunching or cracking noises when steering, caused by corrosion and wear from dust and moisture ingress.
Replacing the wiper seal in a timely manner helps prevent costly CV joint and bearing failures.
Technical Specifications
| Brand | TOYOTA |
|---|---|
| Weight | 0.230 kg |
Compatible Vehicles
| Make | Model | Engine | Year | Notes |
|---|---|---|---|---|
| Toyota | Land Cruiser 100 (J100) | 4.5 (1FZFE) | 1998 - ... | SEAL SUB-ASSY, STEERING KNUCKLE OIL (FZJ105, 1FZFE) |
| Toyota | Land Cruiser 70 (J70) | 4.2 D (1HZ) | 1999 - 2007 | SEAL SUB-ASSY, STEERING KNUCKLE OIL (HZJ78, 1HZ) |
| Toyota | Land Cruiser 70 (J70) | 4.5 (1FZF) | 1999 - 2007 | SEAL SUB-ASSY, STEERING KNUCKLE OIL (FZJ74, 1FZF) |
| Toyota | Land Cruiser 70 (J70) | 4.0 (1GRFE) | 2007 - 2011 | SEAL SUB-ASSY, STEERING KNUCKLE OIL (GRJ70, 1GRFE) |
| Toyota | Land Cruiser 80 (J80) | 4.0 (3FE) | 1992 - 1998 | SEAL SUB-ASSY, STEERING KNUCKLE OIL (FJ80, 3FE) |
| Toyota | Land Cruiser 80 (J80) | 4.5 (1FZF) | 1992 - 9999 | SEAL SUB-ASSY, STEERING KNUCKLE OIL (FZJ80, 1FZF) |
| Toyota | Lexus LX (J80) | 4.5 (1FZFE) | 1995 - 1998 | SEAL SUB-ASSY, STEERING KNUCKLE OIL (FZJ80, 1FZFE) |
Inquire About This Part
Not sure if this fits? Send us your VIN number and we will double check for you.
