TOYOTA 48061-60010 Lower Control Arm Bushing
Genuine part. Fitment information is for reference only. To ensure 100% compatibility, please send us a message with your VIN number before ordering.
Categories
Product Description
The genuine TOYOTA 48061-60010 lower control arm bushing (BUSH SUB-ASSY, LWR) is a critical suspension component responsible for the stability and comfort of the vehicle's front suspension system. Genuine OEM parts guarantee precise fitment, maximum durability, and the preservation of original driving dynamics.
Function and Operating Principle
The lower control arm bushing provides a flexible connection between the lower control arm and the vehicle chassis or subframe. Its primary function is to absorb and dampen radial, axial, and torsional forces resulting from road irregularities, minimizing noise, vibration, and harshness (NVH) transmitted to the cabin. In addition, it plays a vital role in maintaining precise suspension geometry (camber and toe) during acceleration, braking, and cornering.
Technical Features and Material Construction
- Premium Material Quality: Outer and inner sleeves made from high-carbon, corrosion-resistant steel for structural integrity.
- Specialized Elastomer: High-density, vulcanized natural rubber compound providing excellent fatigue resistance and withstanding ozone, road salt, engine oil, and extreme temperature fluctuations.
- Precision Manufacturing: Tolerances adhering to strict Toyota OEM standards ensure perfect press-fit into the control arm, preventing deformation during installation.
Common Symptoms of Wear
Bushings are natural wear items that degrade over time due to constant dynamic loads and environmental exposure. Key signs of failure include:
- Knocking, rattling, or squeaking noises from the suspension, particularly when driving over bumps or during sharp turns.
- Vague, imprecise steering response and reduced driving stability at high speeds.
- Abnormal, uneven tire tread wear.
- Visually apparent cracks, dry rotting, tearing, or complete detachment of the rubber from the metal sleeve.
Technical Specifications
- Manufacturer: TOYOTA (Original Equipment Manufacturer)
- Part Number (SKU): 48061-60010
- Part Name: Lower Control Arm Bushing (Bush Sub-Assy, Lower)
- Installation Position: Front axle, lower control arm
- Construction: Rubber-to-metal bonded bushing
Technical Specifications
| Brand | TOYOTA |
|---|---|
| Weight | 0.318 kg |
Compatible Vehicles
| Make | Model | Engine | Year | Notes |
|---|---|---|---|---|
| Toyota | Land Cruiser 100 (J100) | 4.5 (1FZFE) | 1998 - ... | BUSH, LOWER ARM (FZJ105, 1FZFE) |
| Toyota | Land Cruiser 70 (J70) | 4.2 D (1HZ) | 1999 - 2004 | BUSH, LOWER ARM (HZJ71, 1HZ) |
| Toyota | Land Cruiser 70 (J70) | 4.5 (1FZF) | 1999 - 2009 | BUSH, LOWER ARM (FZJ71, 1FZF) |
| Toyota | Land Cruiser 70 (J70) | 4.0 (1GRFE) | 2007 - 2012 | BUSH, LOWER ARM (GRJ71, 1GRFE) |
| Toyota | Land Cruiser 80 (J80) | 4.0 (3FE) | 1990 - 1998 | BUSH, LOWER ARM (FJ80, 3FE) |
| Toyota | Land Cruiser 80 (J80) | 4.5 (1FZF) | 1992 - 9999 | BUSH, LOWER ARM (FZJ80, 1FZF) |
| Toyota | Lexus LX (J80) | 4.5 (1FZFE) | 1995 - 1998 | BUSH, LOWER ARM (FZJ80, 1FZFE) |
