TOYOTA 90520-46014 Drive Shaft Snap Ring
Genuine part. Fitment information is for reference only. To ensure 100% compatibility, please send us a message with your VIN number before ordering.
Product Description
The genuine OEM Toyota 90520-46014 drive shaft snap ring is a precision retaining component that plays a critical role in the safe operation of the vehicle drivetrain. This specialized snap ring provides axial (longitudinal) retention of the drive shaft within the CV joint or differential, preventing unwanted movement or disengagement during operation.
Technical Features and Function:
- Premium Material Quality: Made from high-strength, hardened spring steel, providing excellent elasticity and durability under continuous mechanical stress and vibration.
- Precise Fit: As an authentic OEM part, it ensures exact dimensional accuracy and strict adherence to factory tolerances, eliminating free play caused by improper retention.
- Critical Safety Role: Prevents the axle shaft from sliding out of the wheel hub or transmission/differential, which would lead to an immediate loss of drive and serious safety hazards.
When is Replacement Necessary?
The snap ring must be replaced whenever the drive shaft or constant velocity (CV) joint is disassembled, serviced, or replaced. During removal, the ring can deform and lose its radial spring tension, making reuse unsafe. A fatigued, stretched, or damaged snap ring cannot properly secure the shaft, potentially causing it to dislodge.
Technical Specifications:
- Manufacturer: TOYOTA (Genuine OEM)
- Part Number: 90520-46014
- Part Type: Drive Shaft Snap Ring (Ring, Snap)
- Material: Hardened spring steel
- Fitting Position: CV joint / differential-side shaft end
Technical Specifications
| Brand | TOYOTA |
|---|---|
| Weight | 0.007 kg |
Compatible Vehicles
| Make | Model | Engine | Year | Notes |
|---|---|---|---|---|
| Toyota | Granace (GDH303) | 2.8 D-4D (1GDFTV) | 2019 - 9999 | RING, SNAP (FOR REAR AXLE SHAFT RH) (GDH303, 1GDFTV) |
| Toyota | Hiace (H300) | 2.8 D-4D (1GDFTV) | 2019 - ... | RING, SNAP (FOR REAR AXLE SHAFT RH) (GDH322, 1GDFTV) |
| Toyota | Land Cruiser 200 (J200) | 4.7 (2UZFE) | 2007 - 2012 | RING, SNAP (FOR REAR AXLE SHAFT RH) (UZJ200, 2UZFE) |
| Toyota | Land Cruiser 200 (J200) | 4.6 (1URFE) | 2007 - ... | RING, SNAP (FOR REAR AXLE SHAFT RH) (URJ200, 1URFE) |
| Toyota | Land Cruiser 200 (J200) | 4.0 (1GRFE) | 2007 - ... | RING, SNAP (FOR REAR AXLE SHAFT RH) (GRJ200, 1GRFE) |
| Toyota | Lexus LX (J200) | 4.6 (1URFE) | 2007 - ... | RING, SNAP (FOR REAR AXLE SHAFT RH) (URJ201, 1URFE) |
| Toyota | Tundra (GSK5) | All Engines | 2006 - ... | RING, SNAP (FOR REAR AXLE SHAFT RH) |
Inquire About This Part
Not sure if this fits? Send us your VIN number and we will double check for you.
