TOYOTA 11328-30020 Timing Belt Cover Gasket No. 1
Genuine part. Fitment information is for reference only. To ensure 100% compatibility, please send us a message with your VIN number before ordering.
Categories
Product Description
The genuine Toyota timing belt cover gasket with part number 11328-30020 (Timing Belt Cover Gasket No. 1) is an essential component of the timing drive protection system. The gasket ensures a hermetic seal between the timing belt cover and the engine block, preventing dust, moisture, mud, and other abrasive external contaminants from entering the timing compartment. Maintaining a clean and dry environment is critical to maximizing the service life of the timing belt, tensioner, and idler pulleys.
Over time and under continuous engine temperature fluctuations, the factory sealing material can lose elasticity, harden, or crack, compromising the cover's seal. Replacing the cover gasket is strictly recommended during timing system servicing and periodic timing belt replacement to maintain optimal protection.
Technical Specifications
- Manufacturer: TOYOTA (Genuine OEM part)
- Part Number: 11328-30020
- Designation: Timing Belt Cover Gasket (Gasket, Timing Belt Cover, No. 1)
- Material: Oil- and heat-resistant elastomer sealing material
- Fitting Position: Engine front face / timing belt cover No. 1
- Compatible Engine Types: 2.5 D-4D (2KD-FTV), 3.0 D-4D (1KD-FTV)
Vehicle Compatibility
- Toyota Fortuner (GGN50) 3.0 D-4D [2005 - ...] (GASKET, TIMING BELT COVER, NO.1 (KUN50, 1KDFTV))
- Toyota Hilux (N10/N20/N30) 2.5 D-4D [2004 - 2016] (GASKET, TIMING BELT COVER, NO.1 (KUN15, 2KDFTV))
- Toyota Hilux (N10/N20/N30) 3.0 D-4D [2004 - 2016] (GASKET, TIMING BELT COVER, NO.1 (KUN26, 1KDFTV))
- Toyota Hilux (N140-N170) 2.5 D-4D [2004 - 2004] (GASKET, TIMING BELT COVER, NO.1 (KDN155, 2KDFTV))
- Toyota Hilux (N140-N170) 3.0 D-4D [2004 - 2004] (GASKET, TIMING BELT COVER, NO.1 (KDN160, 1KDFTV))
- Toyota Innova / Kijang (AN40) 2.5 D-4D [2004 - ...] (GASKET, TIMING BELT COVER, NO.1 (KUN40, 2KDFTV))
Technical Specifications
| Brand | TOYOTA |
|---|---|
| Weight | 0.030 kg |
Compatible Vehicles
| Make | Model | Engine | Year | Notes |
|---|---|---|---|---|
| Toyota | Fortuner (GGN50) | 3.0 D-4D (1KDFTV) | 2005 - ... | GASKET, TIMING BELT COVER, NO.1 (KUN50, 1KDFTV) |
| Toyota | Hilux (N10/N20/N30) | 2.5 D-4D (2KDFTV) | 2004 - 2016 | GASKET, TIMING BELT COVER, NO.1 (KUN15, 2KDFTV) |
| Toyota | Hilux (N10/N20/N30) | 3.0 D-4D (1KDFTV) | 2004 - 2016 | GASKET, TIMING BELT COVER, NO.1 (KUN26, 1KDFTV) |
| Toyota | Hilux (N140-N170) | 2.5 D-4D (2KDFTV) | 2004 - 2004 | GASKET, TIMING BELT COVER, NO.1 (KDN155, 2KDFTV) |
| Toyota | Hilux (N140-N170) | 3.0 D-4D (1KDFTV) | 2004 - 2004 | GASKET, TIMING BELT COVER, NO.1 (KDN160, 1KDFTV) |
| Toyota | Innova / Kijang (AN40) | 2.5 D-4D (2KDFTV) | 2004 - ... | GASKET, TIMING BELT COVER, NO.1 (KUN40, 2KDFTV) |
Inquire About This Part
Not sure if this fits? Send us your VIN number and we will double check for you.
